SARS-CoV-2, which remains enigmatic, has rapidly spread worldwide, leading to high economic losses and threats to public health. Within 6 months after SARS-CoV-2 was first reported, five kinds of animals were developed into models in which to study COVID-19: the mouse, ferret, tree shrew, golden hamster, and a NHP species. Murine models of COVID-19 were developed by genetic manipulation of human ACE2 through transgene expression,9 CRISPR-cas9 editing,5 and the transient overexpression of ACE2,18 which makes mice susceptible to SARS-CoV-2 infection. However, due to the many differences in their genetics, anatomy and physiology, these murine models of COVID-19 are not suitable for studies of COVID-19 pathogenesis. The ferret and golden hamster are naturally susceptible to SARS-CoV-2 infection.11,12 However, they are also genetically different from humans and are not ideal animal models for studies of vaccines and pathogenesis. The tree shrew is relatively genetically close to primates and can act as an alternative experimental animal to NHPs.19 Unfortunately, our recent study showed that the tree shrew is not susceptible to SARS-CoV-2 infection and may instead be an asymptomatic carrier.20

NHPs are widely recognized as ideal animal models for emerging and re-emerging diseases, including SARS16,21,22 and Middle East respiratory syndrome.23 To date, there have been four reports of NHP (Old World monkeys) models of COVID-1914,15,24,25 that recapitulate different aspects of COVID-19, but these models have also raised some debate, probably due to differences in animal species (M. mulatta and M. fascicularis), virus strain, challenge route, and methods of evaluation. Using comparative analysis, our study revealed that M. mulatta is a more susceptible species to SARS-CoV-2 infection than M. fascicularis and C. jacchus.

Host ACE2 is one of the most important receptors for SARS-CoV-2.26 At the molecular level, amino acid alignment of the ACE2 fragments that interact with the receptor-binding domain of the SARS-CoV-2 spike glycoprotein revealed the ACE2 fragments from M. mulatta, M. fascicularis, and humans share the same sequence, while those from C. jacchus and humans differ by four amino acids (Supplementary Fig. 4). These four amino acids are critically involved in the binding of ACE2 to SARS-CoV-2.27 Y41 and Q42 in hACE2, which bind the S protein via the formation of hydrogen bonds, are substituted by H and E, respectively, in C. jacchus ACE2.28 These findings may partially explain the lower susceptibility of C. jacchus compared to the other species examined to SARS-CoV-2 infection. The sequences of this critical domain in the ACE2 receptors from mouse and ferret differ from that in the hACE2 receptor by eight and seven amino acids, respectively. However, this domain in tree shrew ACE2 differs from that in human ACE2 by ten amino acids. Surprisingly, the golden hamster and human ACE2 receptors differ by only two amino acids. In fact, differences in the number of these amino acids parallel the susceptibility to SARS-CoV-2 infection.

The NHP model in this study recapitulates several clinical features of COVID-19. First, the increased body temperature and abnormal chest radiograph of our model simulate two typical clinical signs in COVID-19 patients, fever and pneumonia, respectively.29,30,31 Importantly, gross lesions of the lungs after necropsy strikingly matched the abnormal spots on chest radiographs taken right before necropsy.

Detection of viral genomic RNA is the most important evidence for the diagnosis of COVID-19 due to SARS-CoV-2 infection. Genomic SARS-CoV-2 RNA is detectable in samples of bronchoalveolar lavage fluid, sputum, nasal swabs, feces, and blood/serum.32 Specifically, nasal swabs had higher levels of viral RNA at the early stage of infection for ~2 weeks.33 In the present study, the dynamics of viral shedding in the NHP models were similar to those reported in COVID-19 patients. In addition, we noticed a high level of viral shedding via feces that persisted for a long time in four model monkeys (Fig. 2a), suggesting that the fecal–oral route shows great potential risk in the transmission of SARS-CoV-2.34,35 The lung is widely considered to be the target organ of SARS-CoV-2 replication since a large viral copy number was detected in bronchoalveolar lavage fluid from COVID-19 patients.32 At the early stage of infection, we detected high levels of SARS-CoV-2 viral genomic RNA in the lung and nine other tissues (Fig. 2b, c), including the stomach, rectum, bladder, and uterus, which suggests that SARS-CoV-2 may be transmitted through the fecal–oral, urea, and maternal–fetal routes.36,37 Importantly, we also detected viral RNA in the spleen and blood of our model, which is consistent with the clinical findings that SARS-CoV-2 is present in patients’ spleens38 and blood and correlated with the severity of COVID-19.39

In terms of host responses to SARS-CoV-2 infection, our NHP model partially recapitulates COVID-19 through at least three features. Typical histopathology of pneumonia is observed in COVID-19 patients in additional to mild inflammation in liver.40 In addition, secondary lymphoid organs could be directly infected by SARS-CoV-2.38 Consistently, our study revealed that after SARS-CoV-2 infection, M. mulatta and M. fascicularis showed severe histopathological changes in lung, including pneumonia, and inflammation in the spleen and liver (Fig. 4a). The COVID-19-associated cytokine storm is reported to be an important pathogenic factor and a potential promising therapeutic target in COVID-19 patients.4,41 Although not consistent with those in COVID-19 patients, the cytokines induced in our model could be used as markers for the evaluation of anti-inflammatory drugs.42 Elevated serum IL-6 is clinically correlated with the severity of COVID-19 and regarded as an important biomarker.43 In a reported NHP model of COVID-19, the level of IL-6 peaked at 1 dpi and decreased to 0 at 3 dpi.14 In this study, we did not detect IL-6, possibly due to our use of a lower challenge dose of virus, which may also have led to the different cytokines profiles and differences in other host responses in the reported NHP models.14 By flow cytometric analysis of peripheral blood from M. mulatta and M. fascicularis, we noticed changes in the abundance of T cells, B cells, and monocytes after viral infection (Supplementary Fig. 2), indicating the induction of host immune responses and transient lymphopenia by SARS-CoV-2 infection.40

The NHP models of COVID-19 play critical roles in the research and development of SARS-CoV-2 vaccines. So far, among four NHPs modes of COVID-19 reported, three models are in rhesus monkey (M. mulatta) and one in cynomolgus monkey (M. fascicularis). Rhesus monkey models are widely used in evaluation of SARS-CoV-2 vaccine. In fact, four SARS-CoV-2 vaccines are all evaluated in rhesus monkeys, including two inactivated vaccines,44,45 one adenoviral vectored vaccine46 and one DNA vaccine.47 Our results in this study further confirmed that rhesus monkey is a good animal model for evaluation of vaccines against SARS-CoV-2.

In conclusion, we have established a NHP model of COVID-19 through comparative analysis of the clinical symptoms, viral replication and tissue tropism, and host responses to SARS-CoV-2 infection among three species from two families of NHPs in one system. Ultimately, this study identified M. mulatta as suitable for the study of SARS-CoV-2 infection, as it most closely recapitulated human-like conditions. The use of this model is promising for the development of COVID-19 drugs and vaccines and other basic studies.
